Cable Tray Connection Piece Production Line
This equipment uses a feeding mechanism to clamp the plates to be processed into a punching mechanism, which punches the processed plates. This process does not require manual feeding, ensuring the safety of workers, saving time and effort, and improving plate production efficiency. Eliminate the need for bulky punches, reduce noise and reduce costs.
Introduction: The cable tray connector molding line is an innovative and efficient solution for the production of high-quality cable tray connectors. This advanced manufacturing process ensures precise shaping and assembly of the connectors, resulting in reliable and durable connections for various cable tray systems.
Features and Benefits: 1. Precision Molding: The molding line utilizes cutting-edge technology to achieve accurate and consistent shaping of the connectors. This ensures a perfect fit and seamless integration with cable tray components. 2. Efficient Production: The automated nature of the molding line allows for streamlined production and quick turnaround times. This maximizes productivity and minimizes lead times, making it ideal for large-scale manufacturing operations. 3. High-Quality Finish: The molding process ensures a smooth and uniform finish on each connector, enhancing the overall aesthetics of the cable tray system. This not only improves the visual appeal but also facilitates ease of installation. 4. Durability and Reliability: The connectors produced on the molding line undergo rigorous quality control measures to guarantee exceptional durability and reliability. They can withstand heavy loads, harsh environments, and extreme temperatures, ensuring long-lasting performance. 5. Versatility: The molding line accommodates a wide range of cable tray connector designs and sizes, making it suitable for various industrial applications. It can produce connectors for both standard and customized cable tray systems, offering flexibility and adaptability. Overall, the cable tray connector molding line combines advanced technology, efficient production processes, and superior quality control to deliver high-performance connectors for cable tray systems. With its precision molding, durability, and versatility, it is the ideal choice for manufacturers seeking optimal solutions in cable tray connector production.
Technical Parameters
Serial number | main component | Configuration |
1 | Unwinding and leveling integrated machine | 1. Type 300 manual core expansion 4. With brake function 2. Passive discharging 5. Leveling up 3 and down 4 (with power) 3. Bearing capacity 1.5 tons |
2 | Punching and bending parts | 1、1. Hydraulic punching and bending 4. Hydraulic punching and bending 2、2. Feeding guide 5. Hydraulic system 1 set 11KW 3、Servo motor feeding, pneumatic clamp 6. Single and double row punches can be switched |
3 | Control cabinet | 1. The entire line adopts PLC control and touch screen human-machine interface to realize human-computer interaction. 2. Hardware configuration: There is a manual operation panel on the power distribution cabinet console and next to the machine. 3. Operation mode: manual/automatic. In the manual state, it can operate as a stand-alone machine for easy maintenance; in the automatic state, it can operate across the entire line; it is equipped with an emergency stop button, making it easy to handle emergencies and ensuring the safety of equipment and operators. |
